1. Perforated Cable Trays

Designed for optimal heat dissipation and easy cable tying in instrumentation, power, and control cable runs.

• Width Options: 50 mm, 100 mm, 150 mm, 300 mm, up to 1000 mm.
• Side Heights: 50 mm, 75 mm.
• Material Thickness: 2.0 mm to 2.5 mm Hot-Rolled Carbon Steel.
• Perforation Pattern: Standardized 10 x 20 mm slots for uniform airflow and structural stability.

2. Ladder Cable Trays

Engineered to support heavy-duty, large-diameter high-voltage power distribution cables over long structural spans.

• Width Options: Standard widths up to 600 mm.
• Side Heights: 50 mm to 100 mm profiles.
• Design Advantage: Maximizes ventilation and airflow around high-load power lines while offering robust rung-to-side-rail structural strength.

3. Raceways / Trunking / Box Type Trays

Enclosed cable protection channels designed to shield sensitive data, signal, and low-voltage lines from external physical damage or interference.

• Profiles: Available in 100 x 38 mm, 150 x 75 mm, and 200 x 100 mm combinations.
• Covers: Supplied with matching 1.6 mm thick protective covers.

4. Wire Mesh Cable Trays

Lightweight, highly flexible grid routing systems preferred for fiber optic, networking, and cleanroom data distribution. Their open structure enables rapid installation, easy cable access, and excellent airflow in temperature-sensitive environments.

Material Finishes & Protective Coatings

To combat varying atmospheric conditions, Pioneer provides three distinct, high-durability surface treatment finishes:

Technical Specifications & Manufacturing Tolerances

We adhere strictly to industrial manufacturing rules to provide error-free alignment on-site:

• Length Tolerance: ±10 mm
• Width Tolerance: ±3 mm
• Height Tolerance: ±2 mm
• Coupling Systems: Supplied with dual dedicated plate couplers (e.g., 25 x 180 mm, 25 x 200 mm, or 65 x 180 mm profiles).
• Hardware Kits: Equipped with M8 x 20 mm round-head or hex-head fasteners with an anti-corrosive Electro-Zinc or Electro-Galvanized plating finish.
