Differential Pressure Transmitters are crucial components in a wide array of industrial and process applications, offering several key advantages :
- Remote Monitoring : Track pressure differences from a central control room or any location with network access, eliminating the need for constant on-site manual checks.
- Precise Process Control : Use the transmitter's output signal to control valves, pumps, and other equipment, optimizing process efficiency and maintaining desired conditions.
- Flow Measurement : When used with primary flow elements like orifice plates, Venturi tubes, or flow nozzles, differential pressure transmitters accurately determine flow rates.
- Liquid Level Measurement : In sealed tanks, differential pressure transmitters can accurately measure liquid levels by sensing the pressure difference between the bottom and top of the tank.
- Filter Monitoring : Track the pressure drop across filters to determine when cleaning or replacement is necessary, preventing system inefficiencies and potential damage.
- Data Logging and Analysis : Record pressure difference trends over time for predictive maintenance, troubleshooting, and process optimization.
- Integration with Control Systems : Seamlessly interface with PLCs (Programmable Logic Controllers), DCS (Distributed Control Systems), and SCADA (Supervisory Control and Data Acquisition) systems.
Applications
- HVAC : Monitoring airflow, filter status, and building pressure.
- Water and Wastewater Treatment : Measuring flow rates, filter performance, and pump efficiency.
- Oil and Gas : Monitoring pipeline flow, wellhead pressure, and refinery processes.
- Chemical Processing : Controlling flow rates, monitoring reactor pressure, and ensuring process safety.
- Pharmaceuticals : Maintaining cleanroom environments and monitoring critical processes.
- Food and Beverage : Measuring flow rates, ensuring product quality, and monitoring sanitation processes. Power Generation: Measuring flow in boiler.
Why Choose Pioneer for Differential Pressure Transmitters?
- High Accuracy and Reliability : Our transmitters provide precise and consistent measurements, even in challenging environments.
- Robust Construction : Built to withstand harsh industrial conditions, including vibration, temperature fluctuations, and corrosive media.
- Wide Range of Options : We offer transmitters with various pressure ranges, output signals, connection types, and materials to meet your specific needs.
- Easy Installation and Configuration : Designed for straightforward installation and setup.
- Expert Technical Support : Our team is available to assist you with selection, installation, and troubleshooting.
- Competitive prices
| Specification | Details |
|---|---|
| Enclosure | IP 65 Enclosure |
| Output | 4-20 mA or 0-10 VDC Output |
| Accuracy (optional) | ± 0.25% of F.S. optional accuracy |
| Maximum Pressure | Ranges 5 PSI (35 kPa) = 15 PSI (100kPa) Max; Ranges > 5PSI (35 kPa) = 30 PSI (200 kPa) Max |
| Media Compatibility | Air and compatible non combustible, non corrosive gasses |
| Accuracy | ± 0.5% of F.S. |
| Operating Temperature Range | -100F to 150F (-25C to 70C) |
| Thermal Effect | ± 0.028% F.S/°F (± 0.050%/°C) |
| Stability | ± 0.25% of F.S./year |
| Output Signal | 4-20 mA, 2 wire or 0-10VDC, 3 WIRE |
| Loop Resistance | 250 Ω 24 VDC |
| Power Supply | 12-30 VDC |
| Enclosure Rating | IP 65 |
| Housing Material | Fireproof ABS, UL94V0 |
| Electrical Connections | Screw terminals |
| Hysteresis | ± 0.15% of F.S |
| Non-linearity | ± 0.10% of F.S |
| Electricity Entry | PG7 cable gland |
| Process Connections | Barbed fittings for 3/16" flexible tubing |
| Agency Approval | CE, RoHS |
| Calibration Protocol | COML |
